CPQ‑YD

LPG Forklift

☑ The emission meets EC and EPA new regulation.

☑ Wide mast with good visibility.

☑ Wide space for boarding and driving, increasing leg space.

1500‑5000kg

Load Capacity

6000mm

Max Lifting Height

6°

Mast Forward Tilt Angle

Operation console

The operating console includes important components such as operating levers, instrument panels and other core parts, which are used to control the forklift and display the vehicle's status and performance parameters and other core functions.

Thickened mast

The mast is an important part of the forklift, enhancing its load‑bearing capacity and durability. It is responsible for lifting and lowering the load and providing horizontal control. Thickened masts are usually made of high‑strength materials to increase stability.

Solid tires

Solid tires are an industrial tire suitable for vehicles traveling under harsh conditions such as low speed and high load. They are significantly superior to pneumatic tires in terms of safety, durability and economy and are widely used in various industries.

Liquefied petroleum gas

Liquefied petroleum gas forklift (LPG forklift) is a forklift that uses liquefied petroleum gas (LPG) as fuel. It has good power performance, is suitable for long‑term operation, has low vibration and noise, low emissions and low consumption cost.

Features

Products you can trust.

Parking brake with safety protection device, when parking brake is working, the forklift will not move even the direction lever is turned.

Ergonomic design, comfortable seats and spacious cab.

Easy‑to‑use features and a range of optional extras allow you to customize your forklift to meet the needs of the task.

Forklifts are used on construction sites, building material suppliers, shipyards, metal and wood processing industries, and transport and logistics companies.

Specs & Compare

Technical specifications for LPG Forklift

Here are the key specifications for this product model. Want more details? Download the brochure or contact us.

Load Capacity	1500‑5000kg
Max Lifting Height	6000mm
Load Center Distance	500mm
Overall Length	3180‑4190mm
Over Width	1090‑1480mm
Over Height	2050‑2240mm
Mast Forward Tilt Angle	6°
Mast Tilted Backward	12°
Forklift Weight	2900‑6700kg
Min Turning Radius	1950‑2900mm
Max Working Speed	14/15‑18/19km/h
