CPC 4.0‑5.0T

4.0‑5.0T Diesel forklift

☑ Low‑position instrument frame and wide‑view mast design provide the driver with a wider field of vision.

☑ Forklifts with different hydraulic and mechanical transmission systems available

☑ A variety of power models are available, complying with the latest environmental protection standards, energy saving, shock absorption and noise reduction

4000‑5000kg

Load Capacity

6000mm

Max Lifting Height

6°

Mast Forward Tilt Angle

Operation console

The operating console includes important components such as operating levers, instrument panels and other core parts, which are used to control the forklift and display the vehicle's status and performance parameters and other core functions.

Engine

A compression ignition internal combustion engine that uses diesel as fuel is also called a diesel engine. Its working principle is to generate high temperature through compressed air to ignite atomized diesel, converting heat energy into mechanical power.

Fork

The fork is the most commonly used pickup device for forklifts, which is why the forklift is named so. A forklift is equipped with two forks shaped like the letter L. The horizontal section of the fork is the working part for placing the goods.

Tire

It has good shock absorption effect, can reduce vibration and impact during driving, and improve driving comfort; it performs well under working conditions and is suitable for most working environments.

Features

Products you can trust.

Reinforced high‑speed gearbox, strong power, fast running speed and higher operating efficiency

Advanced manufacturing technology, integrated drawn hood, beautiful appearance and high strength

Equipped with wide‑base tires, tire life is greatly improved and durable

Adopting a fully hydraulic steering device, the turning radius is small, the steering is light and flexible, safe and reliable

The smaller front overhang design effectively reduces the front axle load under full load and greatly increases the life of the front tires and drive axle.

Specs & Compare

Technical specifications for 4.0‑5.0T Diesel forklift

Here are the key specifications for this product model. Want more details? Download the brochure or contact us.

Load Capacity	4000‑5000kg
Max Lifting Height	6000mm
Load Center Distance	500mm
Overall Length	4000‑4190mm
Over Width	1290‑1480mm
Over Height	2180‑2240mm
Mast Forward Tilt Angle	6°
Mast Tilted Backward	12°
Forklift Weight	4950‑6700kg
Min Turning Radius	2710‑2900mm
Max Working Speed	18/19‑19/19km/h
