The whole machine has a compact structure and will not be limited by the size of the working space. It has a small turning radius and can easily enter a small space for operation. It is flexible and easy to operate, sensitive to operation, and has higher
By reducing the drag during digging, the teeth can improve the efficiency of the excavator, especially when handling tough materials.
It has the features of low noise, small vibration, large traction, strong adaptability, etc. It is particularly suitable for use in agriculture, orchard greenhouses, construction sites, road excavation and indoor operations
The cab design of a mini excavator has multiple functions, mainly including providing a good view, a comfortable operating environment and safety.
It adopts Laidong engine; it is equipped with a cab and is suitable for all kinds of weather.
The standard mechanical operation can be equipped with hydraulic pilot operation, imported and joint venture hydraulic components, which are light and flexible in operation, soft in action, and can ensure precise operation.
Ultra‑stable chassis, large‑scale travel reducer with strong driving force, and the attached boom deflection can be used for side digging at an angle, suitable for safe operation in small spaces.
Compared with the same level, the size has been lengthened (digging depth and unloading height), and the turntable has been enlarged (optimizing the defects of old teeth).
Enlarging the upper and lower frames (the large wheelbase of the lower plate increases the stability, and the layout of the upper plate is loose for maintenance).
Enlarging the crawler belt (the belt surface is wide and non‑slip, the internal teeth are heightened and the belt is not easy to drop), and the walking system is enlarged (improving the climbing force).
The full surge cover (the machine cover, shed and fuel tank are electroplated and anti‑rust, it is not easy to rust in rainy days, and the fuel tank is cleaner) is thicker and more economical and applicable.
Standard auxiliary pipelines, various auxiliary devices can be configured.
Here are the key specifications for this product model. Want more details? Download the brochure or contact us.
| Vehicle weight | 3000kg |
| Machine size | 4200*1300*2300mm |
| Engine | LaiDong LL385B |
| Engine power | 22.1KW |
| Maximum Digging Radius | 4200mm |
| Maximum Digging Depth | 2350mm |
| Maximum Digging Height | 3200mm |
| Maximum dump height | 2450mm |
| Minimum turning radius | 2300mm |
| Chassis width | 1300mm |
